A wider clinical workspace
The 16:10 panel adds vertical workspace compared with 1920 × 1080 displays. Images, tool palettes and patient information can share the desktop.
EIZO RadiForce MX243W 24.1-inch 2.3MP DICOM Medical Monitor
$0.00
Skip to product information
EIZO RadiForce MX243W 24.1-inch 2.3MP DICOM Medical Monitor
$0.00
EIZO RADIFORCE MX243W · 2.3MP MEDICAL DISPLAY
A 16:10 medical review display with room for images and tools.
The EIZO RadiForce MX243W is a 24.1-inch color DICOM medical monitor with 1920 × 1200 native resolution. Its 2.3MP-class widescreen panel provides space for medical images, patient information and application controls.
Plan your reading workstation
This MX-Series display is positioned for medical image viewing and clinical review. Match its resolution and 220 cd/m² recommended calibration brightness to the intended modality, room conditions and facility quality-control policy.
MX243W features for your imaging workflow
DICOM calibration and consistency
RadiCS LE supports simplified DICOM Part 14 calibration. The listed backlight sensor and brightness stabilization help manage luminance; Digital Uniformity Equalizer addresses screen variation.
Mixed images and simple connections
Hybrid Gamma PXL supports grayscale and color content on the same panel. DisplayPort input and output, DVI-D and a USB 2.0 hub support compatible desk configurations.
EIZO RadiForce MX243W technical specifications
Display & calibration
| Manufacturer / model | EIZO RadiForce MX243W |
|---|---|
| Screen / panel | 24.1-inch color IPS; LED backlight |
| Native resolution | 1920 × 1200; 2.3MP class; 16:10 |
| Typical brightness | 410 cd/m² |
| Recommended calibration | 220 cd/m² |
| Typical contrast / pixel pitch | 1350:1; 0.270 mm |
| DICOM / uniformity | DICOM Part 14; Digital Uniformity Equalizer |
| Calibration sensor | Backlight sensor; no Integrated Front Sensor listed |
Connections & installation
| Video inputs | 1 × DisplayPort; 1 × DVI-D |
|---|---|
| Video output | DisplayPort daisy chain |
| USB hub | 1 × Type-B upstream; 2 × Type-A downstream (USB 2.0) |
| VESA mounting | 100 × 100 mm |
| Power input / typical use | 100–240V AC, 50/60Hz; 26W |
| Net monitor weight | 7.8 kg with stand; not packaged shipping weight |
Applications & clinical scope
FDA 510(k) K221136 covers radiological image review, analysis and diagnosis by trained medical practitioners. Mammography is excluded; this listing does not claim diagnostic mammography or DBT use.
EIZO lists a backlight sensor for MX243W, not an Integrated Front Sensor or ambient light sensor. Specify any external QC sensor and full RadiCS software separately. No USB-C docking or HDMI input is listed.
Verify PACS compatibility, native-resolution output, reading-room conditions and facility QC requirements before deployment.
One monitor & standard accessories
EIZO lists one DisplayPort cable, one USB Type-A–Type-B cable, an AC power cord, RadiCS LE and documentation with its standard configuration. Contents vary by country and supplied unit; the written quote confirms the actual kit. No workstation, dictation microphone or secondary monitor is included.
Product & purchasing details
One MX243W monitor. Condition, availability, price and shipping are confirmed in your quote. Contact Texel Comp for technical support options.
EIZO lists a standard five-year manufacturer warranty. Confirm the quoted unit's eligibility, remaining coverage and applicable LCD brightness or operating-hour limits before ordering; country and configuration terms can differ.
Send your quantity, workstation, graphics outputs and delivery ZIP code. Installation, full RadiCS, RadiNET Pro and external QC sensors are separate quote items.
MX243W buying & setup questions
Does MX243W have a built-in front calibration sensor?
No Integrated Front Sensor is listed in EIZO's specifications. Its listed sensor is the backlight sensor. Confirm an external sensor and the required QC software if your testing procedure needs them.
Is this a Full HD monitor?
Its native resolution is 1920 × 1200 with a 16:10 aspect ratio, often called WUXGA. That is taller than 1920 × 1080 Full HD and is approximately 2.3 megapixels.
Can MX243W be used for mammography diagnosis?
No. FDA 510(k) K221136 excludes mammography. Its general-radiology indications do not establish diagnostic mammography or DBT use.
Does it include USB-C docking?
No. Video inputs are DisplayPort and DVI-D. The USB 2.0 hub uses a Type-B upstream connection and two Type-A downstream ports.
