01 · DISPLAY
A wide 8MP canvas for radiology.
The 31.5-inch Nano IPS panel displays 3840 × 2160 pixels across a 16:9 workspace. Review your PACS layout with Texel Comp when planning a single wide diagnostic screen.
Product images show the individual monitor. Screen content is illustrative.
DIAGNOSTIC RADIOLOGY
SKU LG-32HL512D-B
LG 32HL512D-B combines a 31.5-inch 8MP Nano IPS display with internal backlight sensor. A 4K diagnostic display for radiology teams that want a wide screen with Picture-by-Picture flexibility and hardware calibration support.
$3,053.89 USD
Check for availabilityLG 32HL512D-B · DIAGNOSTIC RADIOLOGY
A 4K diagnostic display for radiology teams that want a wide screen with Picture-by-Picture flexibility and hardware calibration support.
This listing is for one monitor. Specifications describe the individual display.
Tell Texel Comp which imaging application you use, how many screens you need and which graphics outputs your workstation provides. That information helps match the display to the desk before you order.
TEXEL COMP · PRODUCT DETAILS
Explore the display, workflow features and physical connections as you plan your workstation or installation with Texel Comp.
Manufacturer product photos and feature illustrations. Screen content and multi-monitor arrangements are illustrative; quoted configurations determine included equipment.
01 · DISPLAY
The 31.5-inch Nano IPS panel displays 3840 × 2160 pixels across a 16:9 workspace. Review your PACS layout with Texel Comp when planning a single wide diagnostic screen.
02 · RESOLUTION MODES
LG provides 8MP, 6MP and 4MP resolution modes. Select the mode that suits the connected system; confirm the graphics output and application settings before deployment.
03 · MULTI-SOURCE WORKFLOW
Picture-by-Picture supports two 4MP image areas. LG Dual Controller software also supports control of compatible connected computers using one keyboard and mouse. Ask Texel Comp to review the connections for your setup.
04 · BRIGHTNESS CONTROL
An internal backlight sensor adjusts LED backlight output to help maintain the target luminance over time. Hardware calibration support works alongside your installation’s display quality-control process.
05 · COLOR DISPLAY MODE
Clinical Pathology Mode provides a color-display setting for pathology images. Choose the display mode for the material being viewed and confirm your application’s color-management requirements.
06 · DESK CONFIGURATION
Height, tilt and two-way pivot adjustments support landscape or portrait arrangements. The illustration shows two monitors; this listing supplies one display. Texel Comp can help plan your display arrangement.
07 · REAR CONNECTIVITY
The rear connector area provides DisplayPort and HDMI video inputs plus a USB hub. Share your workstation’s output configuration with Texel Comp to review the required connections.
| Exact model | LG 32HL512D-B |
|---|---|
| Screen | 31.5 inches |
| Native resolution | 8MP · 3840 × 2160 |
| Panel / aspect | Nano IPS · 16:9 |
| Typical brightness | 450 cd/m² |
| Typical contrast | 1,300:1 |
| Calibration sensor | Internal backlight sensor |
|---|---|
| Calibration support | PerfectLum and LG Calibration Studio Medical support; confirm the supplied application, version and license in your quote |
| Resolution modes | 8MP; Picture-by-Picture: two 4MP areas |
| Connectivity | 2 × DisplayPort 1.4; 1 × HDMI 2.0; USB hub |
| Stand adjustment | Height, tilt and pivot |
| Condition / warranty | New · 5-year manufacturer limited warranty |
Brightness shown is the manufacturer’s typical specification, not a promise of calibrated luminance. Confirm the calibration target, software version and display connection for your installation.
FDA-cleared for radiological image display; not intended for mammography.
Use the exact model number when comparing quotes. Ask Texel Comp to confirm availability, supplied accessories, delivery timing and applicable U.S. manufacturer warranty terms for your order.
A monitor purchase does not include a computer, PACS software license or deployment service unless those items are explicitly listed in your quote.
No. Both are wide-format 8MP models, but their panels, brightness, sensor systems and cleared applications differ. The 32HL512D-B is not intended for mammography.
Confirm your graphics card’s output, supported resolution and required cable connection. Send your workstation model and intended screen arrangement to Texel Comp for help reviewing the setup.
The display’s DICOM support is one part of the installation. Your team should establish and maintain its calibration and quality-control workflow for the intended application.
Yes. Include the exact LG model, monitor quantity, single or paired arrangement and delivery destination. Texel Comp can help you review the display requirements for the order.
LG 32HL512D-B product information / specification sheet
Compare display options in our LG vs Barco medical monitor guide, browse LG medical monitors, or explore complete PACS reading stations.
