01 · CURVED ULTRAWIDE DISPLAY
More space for your information workflow.
The 37.5-inch EV3895 displays 3840 × 1600 pixels. Texel Comp can help plan worklist, reporting and reference windows across this curved screen.
EIZO FlexScan EV389537.5-inch · Curved UWQHD+
PROFESSIONAL WORKLIST MONITOR
EIZO FlexScan EV3895 37.5-inch Curved Ultrawide USB-C Docking Worklist Monitor
SKU EIZO-EV3895
New
The EIZO FlexScan EV3895 provides a 37.5-inch curved 3840 × 1600 workspace with USB-C docking, up to 85 W charging and Picture-by-Picture for up to three sources.
- DISPLAY
- 37.5-inch
Curved IPS - RESOLUTION
- 3840 × 1600 UWQHD+
60 Hz - CONNECTION
- USB-C · up to 85 W
Gigabit Ethernet - WORKSPACE
- Up to 3 sources with PbyP
Height, tilt and swivel
Request a quote
Confirm your workflow, delivery location and final configuration with Texel Comp.
5-year manufacturer warrantyManufacturer terms apply
Contact Texel CompConfiguration and service questions
TEXEL COMP · PRODUCT DETAILS
A closer look at your display.
Explore the display, workflow features and physical connections as you plan your workstation or installation with Texel Comp.
Manufacturer product photos and feature illustrations. Screen content and multi-monitor arrangements are illustrative; quoted configurations determine included equipment.
02 · WORKSPACE
Keep related applications in view.
Its ultrawide canvas offers room for several windows. Check text scaling and viewing distance for the applications you use throughout the day.
03 · MULTI-SOURCE VIEWING
View as many as three connected sources.
Picture-by-Picture supports up to three video inputs at once. Select a layout that suits your connected systems and desktop tasks.
04 · USB SWITCHING
Share a keyboard and mouse across computers.
The USB selection function supports compatible multi-PC arrangements. Plan upstream USB connections and input assignments with Texel Comp.
05 · USB-C DOCKING
Connect a compatible laptop with fewer cables.
USB-C carries video and USB data while delivering up to 85 W charging. Confirm your laptop output and power requirements.
06 · WIRED NETWORK
Use the monitor’s Ethernet connection.
Built-in Gigabit Ethernet can serve a compatible USB-C laptop, helping keep the wired desktop connection available when you dock.
07 · AUTOMATIC BRIGHTNESS
Adjust to the light around your workstation.
Auto EcoView responds to ambient conditions. Configure brightness for your worklist screen and review the position of room lighting.
08 · CONNECTION PANEL
Review the ports as one system.
USB-C, DisplayPort, two HDMI inputs, Ethernet and the USB hub support multiple workstation arrangements. Texel Comp can help map the connections.
EIZO FLEXSCAN EV3895 · PROFESSIONAL WORKLIST MONITOR
A wide, taller workspace for complex desktops.
The EIZO FlexScan EV3895 provides a 37.5-inch curved 3840 × 1600 workspace with USB-C docking, up to 85 W charging and Picture-by-Picture for up to three sources.
Keep reporting tools, worklists and reference documents arranged across one expansive screen. The EV3895's 24:10 format combines ultrawide width with 1600 vertical pixels, providing more document height than a 3440 × 1440 ultrawide.
Choose the display around your workflow
Choose this model when a single broad display can replace the visual separation of multiple monitors. Its multi-source features also support desks that need to move between several connected computers.
EV3895 features for a professional desk
37.5-inch curved UWQHD+
The 3840 × 1600 IPS panel provides a 24:10 workspace for multiple application windows. Plan display scaling and desk depth around the screen's width and your viewing distance.
Docking with up to 85 W power
USB-C supports compatible video, data and laptop charging, with Gigabit Ethernet for a supported host. Four USB Type-A downstream ports provide peripheral connections.
Up to three sources at once
Picture-by-Picture can show up to three compatible video sources. USB selection lets a connected keyboard and mouse move between computers with the required upstream connections.
Adjust the desk around the screen
The stand provides height, tilt and swivel adjustment. Auto EcoView responds to ambient light, and integrated stereo speakers cover basic audio; portrait pivot is not specified.
EIZO EV3895 technical specifications
Display & performance
| Manufacturer / model | EIZO FlexScan EV3895 |
|---|---|
| Screen | 37.5-inch curved IPS; LED backlight |
| Native resolution | 3840 × 1600 UWQHD+; 24:10 |
| Refresh rate | 60 Hz |
| Typical brightness / contrast | 300 cd/m²; 1000:1 |
| Response / pixel density | 5 ms gray-to-gray; 111 ppi |
| Typical / maximum power | 28 W typical; 194 W maximum |
Connections & installation
| Video inputs | 1 × USB-C (DisplayPort Alt Mode); 1 × DisplayPort; 2 × HDMI |
|---|---|
| USB hub | USB-C and 2 × USB-B upstream at 5 Gbps; 4 × USB-A downstream at 5 Gbps |
| USB-C power delivery | Up to 85 W via upstream USB-C |
| Wired networking | RJ45 Gigabit Ethernet (1000BASE-T) |
| Audio | 1 W + 1 W speakers; headphone output |
| Multi-source display | Picture-by-Picture for up to 3 sources; USB selection across connected computers |
| Stand-equipped configuration | 192.7 mm height adjustment; tilt 35° up / 5° down; 70° swivel; no portrait pivot specified |
| VESA mounting | 100 × 100 mm |
| Net weight with stand | 13.2 kg |
Configuration & purchasing
One monitor, configured for your desk
This listing is for one EIZO FlexScan EV3895. Confirm the manufacturer suffix, color, stand configuration and regional accessories in your quote. Specifications above describe the stand-equipped configuration; cables, adapters and mounting hardware depend on the supplied unit.
The manufacturer lists USB-C, DisplayPort, HDMI, power and two USB Type-A to Type-B cables for the standard stand-equipped model.
Listed for worklists, reporting, EHR and office tasks. A DICOM preset does not establish suitability for primary diagnostic interpretation; choose an appropriately specified medical display for diagnostic reading.
Warranty, condition & availability
5-year manufacturer warranty, limited to 30,000 usage hours; confirm eligibility and remaining coverage for the quoted unit.
Condition, availability, shipping, delivery timing and included accessories are confirmed in the final quote. Send the quantity, workstation or laptop model, video outputs and delivery ZIP code so Texel Comp can help plan the connections.
EIZO EV3895 buying & setup questions
Is the EV3895 a 21:9 3440 × 1440 monitor?
No. Its native resolution is 3840 × 1600 and its aspect ratio is 24:10. It provides 1600 vertical pixels on a 37.5-inch curved panel.
Can it show three computers at the same time?
Picture-by-Picture supports up to three compatible video sources. Plan separate video inputs and the necessary USB upstream connections if sharing a keyboard and mouse between computers.
How much USB-C charging power is available?
The upstream USB-C port supplies up to 85 W. Confirm the laptop's video support, cable compatibility and power requirements; it may need its own charger for higher power demands.
Does it have a built-in webcam?
A built-in webcam is not listed for the EV3895. Choose the EV3450XC if integrated conferencing hardware is a priority, or connect a compatible external camera to your host system.
Manufacturer resources & related displays
EIZO EV3895 specifications, manuals & downloads
Prefer integrated conferencing hardware? Compare the EV3450XC.
