01 · 4K MINI LED
Plan a 31.5-inch Mini LED display.
The 3840 × 2160 display uses Mini LED backlighting with local dimming. Review its 4K source requirements and placement with Texel Comp.
LG 32HR734S-W31.5-inch · 4K UHD
SURGICAL MEDICAL DISPLAY
LG 32HR734S-W 31.5-inch 4K Mini-LED 12G-SDI Surgical Monitor
SKU LG-32HR734S-W
New
The LG 32HR734S-W combines a 31.5-inch 4K IPS Mini-LED panel, 12G-SDI connections and optically bonded protective glass for compatible surgical video workflows.
- DISPLAY
- 31.5-inch
Mini-LED LCD - RESOLUTION
- 3840 × 2160
4K UHD - CONNECTION
- 12G-SDI
HDMI / DisplayPort - WORKFLOW
- Up to four-source PBP
HDR10
3-year manufacturer warrantyManufacturer terms apply
Contact Texel CompConfiguration and service questions
SURGICAL MEDICAL DISPLAY
Mini-LED control with the connections your OR needs.
The LG 32HR734S-W combines a 31.5-inch 4K IPS Mini-LED panel, 12G-SDI connections and optically bonded protective glass for compatible surgical video workflows.
Bring local dimming and a larger 4K screen to a surgical video installation that uses supported SDI and digital inputs. HDMI Clone Screen output adds a way to share the configured view with another compatible display.
Plan your video workflow
Choose this model for a 31.5-inch Mini-LED screen with multiple SDI connections. Confirm desired source formats, secondary display arrangement and mounting hardware as part of the configuration.
Explore our medical displays to compare screen sizes and connection options.
TEXEL COMP · PRODUCT DETAILS
A closer look at your display.
Explore the display, workflow features and physical connections as you plan your workstation or installation with Texel Comp.
Manufacturer product photos and feature illustrations. Screen content and multi-monitor arrangements are illustrative; quoted configurations determine included equipment.
02 · 12G-SDI
Connect a compatible 4K SDI source.
12G-SDI supports a 4K signal over one compatible coaxial connection. Confirm the source equipment, cable specification and installation distance before deployment.
03 · MULTIPLE SOURCES
Choose a layout for several feeds.
Picture-in-Picture and up to four Picture-by-Picture areas support multiple inputs. Plan the source arrangement around the video feeds your team uses.
04 · HDMI CLONE OUT
Share the displayed image with another screen.
HDMI Clone Out passes the monitor’s displayed image to a compatible connected display. Ask Texel Comp to review the downstream display and connection plan.
05 · VIEWING SURFACE
Consider reflections in the room.
Optical bonding and the anti-glare viewing surface form part of this model’s design. Review lighting and display placement for the planned installation.
06 · ENCLOSURE
Check protection and mounting requirements.
LG specifies IP45 protection at the front and IP32 for the body. Follow the manufacturer’s mounting, ventilation and cleaning guidance for installation.
07 · REAR CONNECTIONS
Review the complete connector layout.
The rear-port photograph shows the physical video and control connections. Texel Comp can help match the monitor to your existing equipment and required cables.
Technical specifications
Display and performance
| Model / MPN | 32HR734S-W |
|---|---|
| SKU | LG-32HR734S-W |
| Screen | 31.5-inch; 16:9 |
| Panel | IPS LCD with Mini-LED backlight |
| Native resolution | 3840 × 2160 |
| Typical brightness | 800 cd/m² |
| Peak luminance | 2000 cd/m² (peak; content and settings dependent) |
| Contrast | 1000:1 |
| Color | DCI-P3 98% coverage (CIE1976); 10-bit color |
| HDR | HDR10 and HDR Effect |
| Timing | 4K source timing depends on selected input |
Connections and installation
| Video inputs | 1 × HDMI; 1 × DisplayPort; 1 × DVI-D; 4 × SDI (12G / 3G) |
|---|---|
| Video outputs | 1 × HDMI Clone Screen; 4 × SDI (12G / 3G) |
| USB | USB 3.0; 1 upstream / 1 downstream |
| Control | RS-232C |
| Multi-image tools | 2 / 3 / 4-source PBP; PIP; mirror and rotation modes |
| Protection | Optically bonded glass with anti-reflection, anti-fingerprint and anti-glare treatment; IP45 front / IP32 except front; IK06 |
| VESA mounting | 100 × 100 mm; 200 × 200 mm |
| Dimensions / net mass | 751.4 × 469.5 × 65.2 mm; 9.7 kg without stand |
| Power | External power connection; 100–240 V AC, 50/60 Hz; up to 130 W |
| Display settings | LG Calibration Studio hardware calibration; 500 cd/m² brightness stabilization target; input failover |
Configuration and purchasing
Supplied configuration
One LG 32HR734S-W monitor. LG lists no stand; confirm the regional power adapter or cord, cables and accessory kit. Specify the required mount or surgical arm separately.
Specify the source, input timing and cable path for your surgical-video workflow. DICOM tone support alone does not establish diagnostic radiology or mammography indications.
Warranty and support
3-year manufacturer limited warranty, subject to unit eligibility and regional terms. Confirm condition, remaining coverage, availability and delivery with your quote. Contact Texel Comp for configuration and support options.
Request a quote for LG 32HR734S-W with your source equipment, desired layout and mounting requirements.
Frequently asked questions
How is this different from the 32HL714S-W?
The 32HR734S-W adds Mini-LED local dimming, up to 2000 cd/m² peak brightness, optically bonded glass and HDMI Clone Screen output. The 32HL714S-W uses conventional LED backlighting.
Does 1,000,000:1 mean native panel contrast?
LG's local-dimming marketing figure is dynamic contrast. Its technical sheet lists 1000:1 typical panel contrast. Compare equivalent measurements rather than treating these as the same value.
What does HDMI Clone Screen do?
It provides an HDMI output for a compatible second display to reproduce the configured screen. Confirm output timing, cable requirements and the connected display's supported formats.
Can it display four inputs at once?
PBP supports two, three or four compatible sources, and PIP provides an inset view. Confirm the source combinations, signal formats and desired layout during configuration.
