Local dimming and peak brightness
1536 local dimming zones control the Mini-LED backlight. LG specifies 800 cd/m² typical brightness, up to 2000 cd/m² peak brightness and a 500 cd/m² stabilization target.
LG 32HR734S-W 31.5-inch 4K Mini-LED 12G-SDI Surgical Monitor
$0.00
Skip to product information
LG 32HR734S-W 31.5-inch 4K Mini-LED 12G-SDI Surgical Monitor
$0.00
SURGICAL MEDICAL DISPLAY
Mini-LED control with the connections your OR needs.
The LG 32HR734S-W combines a 31.5-inch 4K IPS Mini-LED panel, 12G-SDI connections and optically bonded protective glass for compatible surgical video workflows.
Bring local dimming and a larger 4K screen to a surgical video installation that uses supported SDI and digital inputs. HDMI Clone Screen output adds a way to share the configured view with another compatible display.
Plan your video workflow
Choose this model for a 31.5-inch Mini-LED screen with multiple SDI connections. Confirm desired source formats, secondary display arrangement and mounting hardware as part of the configuration.
Explore our medical displays to compare screen sizes and connection options.
Key features
Optically bonded protective glass
The front glass uses optical bonding with anti-reflection, anti-fingerprint and anti-glare treatment. IP45 front and IP32 non-front ratings describe its tested ingress protection.
SDI and a cloned second view
Four SDI inputs and outputs support specified 12G / 3G signals. HDMI Clone Screen output can mirror the configured view to compatible equipment; verify source and output compatibility.
Tools for multiple sources
Two-, three- and four-source PBP and PIP provide flexible layouts. Mirror, rotation, input failover and LG Calibration Studio support a configured display workflow.
Technical specifications
Display and performance
| Model / MPN | 32HR734S-W |
|---|---|
| SKU | LG-32HR734S-W |
| Screen | 31.5-inch; 16:9 |
| Panel | IPS LCD with Mini-LED backlight |
| Native resolution | 3840 × 2160 |
| Typical brightness | 800 cd/m² |
| Peak luminance | 2000 cd/m² (peak; content and settings dependent) |
| Contrast | 1000:1 |
| Color | DCI-P3 98% coverage (CIE1976); 10-bit color |
| HDR | HDR10 and HDR Effect |
| Timing | 4K source timing depends on selected input |
Connections and installation
| Video inputs | 1 × HDMI; 1 × DisplayPort; 1 × DVI-D; 4 × SDI (12G / 3G) |
|---|---|
| Video outputs | 1 × HDMI Clone Screen; 4 × SDI (12G / 3G) |
| USB | USB 3.0; 1 upstream / 1 downstream |
| Control | RS-232C |
| Multi-image tools | 2 / 3 / 4-source PBP; PIP; mirror and rotation modes |
| Protection | Optically bonded glass with anti-reflection, anti-fingerprint and anti-glare treatment; IP45 front / IP32 except front; IK06 |
| VESA mounting | 100 × 100 mm; 200 × 200 mm |
| Dimensions / net mass | 751.4 × 469.5 × 65.2 mm; 9.7 kg without stand |
| Power | External power connection; 100–240 V AC, 50/60 Hz; up to 130 W |
| Display settings | LG Calibration Studio hardware calibration; 500 cd/m² brightness stabilization target; input failover |
Configuration and purchasing
Supplied configuration
One LG 32HR734S-W monitor. LG lists no stand; confirm the regional power adapter or cord, cables and accessory kit. Specify the required mount or surgical arm separately.
Specify the source, input timing and cable path for your surgical-video workflow. DICOM tone support alone does not establish diagnostic radiology or mammography indications.
Warranty and support
3-year manufacturer limited warranty, subject to unit eligibility and regional terms. Confirm condition, remaining coverage, availability and delivery with your quote. Contact Texel Comp for configuration and support options.
Request a quote for LG 32HR734S-W with your source equipment, desired layout and mounting requirements.
Frequently asked questions
How is this different from the 32HL714S-W?
The 32HR734S-W adds Mini-LED local dimming, up to 2000 cd/m² peak brightness, optically bonded glass and HDMI Clone Screen output. The 32HL714S-W uses conventional LED backlighting.
Does 1,000,000:1 mean native panel contrast?
LG's local-dimming marketing figure is dynamic contrast. Its technical sheet lists 1000:1 typical panel contrast. Compare equivalent measurements rather than treating these as the same value.
What does HDMI Clone Screen do?
It provides an HDMI output for a compatible second display to reproduce the configured screen. Confirm output timing, cable requirements and the connected display's supported formats.
Can it display four inputs at once?
PBP supports two, three or four compatible sources, and PIP provides an inset view. Confirm the source combinations, signal formats and desired layout during configuration.
Resources and related displays
Official LG 32HR734S-W specifications · Manufacturer brochure · Manufacturer support and warranty
Compare Compare the LG 32HL714S-W for a conventional LED 4K IPS option..
